ULXD4Q Quad-Channel Digital Wireless Receiver

Features

• 24-bit/48kHz digital audio delivers clear and accurate sound reproduction
• Extended 20Hz to 20kHz frequency range with flat response
• >120 dB wide dynamic range for excellent signal-to-noise performance
• Up to 60dB of independently adjustable gain for each channel
• Works with a wide selection of Shure mics and transmitter types including the ULXD1 bodypack and ULXD2 handheld transmitters that provide complete mobility for presenters/performers, and the ULXD6 boundary and ULXD8 gooseneck base transmitters to accommodate meeting rooms with flexible seating layouts
• ULX-D receivers are also compatible with QLX-D bodypack and handheld transmitters

• 4-channel receiver operates in the H50: 534 to 598 MHz UHF band
• 64 MHz tuning range lets you run up to 60 channels at the same location in Standard mode or 90 channels in High-Density mode
• Digital Predictive Switching Diversity uses a microprocessor to switch antennas before dropouts occur
• Bodypack frequency diversity ensures uninterrupted audio for mission-critical applications using two discrete bodypacks on a single audio source
• 256-bit AES encryption offers unbreachable privacy—uses unique, randomized encryption key generated every time encryption is enabled
• Interference detection and alerts provide instant confirmation on both the receiver LCD and WWB software when interference is present
• Adding UA874 active antennas or PA805 passive antennas increases the range of your system and offers increased protection against interference
• The UA844+SWB antenna distribution system (available separately) lets you stretch the power of your antenna pairs, giving you more on-air channels in less setup time

• Networked Control
• Ethernet networking enables real-time, precision monitoring, and control of your system, as well as automatic frequency coordination across multiple receivers, using Wireless Workbench, SystemOn, and Axient Spectrum Manager software
• Compatible with external controllers such as AMX and Creston
• Cross subnet control-enabled for management between multiple facilities or venues
• Networked Audio
• Dante support allows you to seamlessly send uncompressed, multichannel audio over standard IP Ethernet networks with low-latency, sample-accurate synchronization, and automatic device discovery—on the same network as IT and control data
• Two RF Cascade Ports
• Allow distribution of RF antenna signals to another receiver unit—ports provide DC bias voltage to power active antennas
• Functionality
• Optimized scanning automatically finds, prioritizes, and deploys the cleanest frequencies to transmitters over IR sync
• Proprietary Gain Ranging optimizes system dynamic range for any input source, eliminating the need for transmitter gain adjustments
• Internal limiter automatically engages to prevent digital clipping of your audio
• Each receiver has an individual gain control and an XLR output with switchable mic/line level
• Quick visual check using audio and RF LED meters with peak indicators
• Intuitive front-panel controls with lockout feature and easily readable LCD with adjustable contrast
• Remote Control: Make adjustments anywhere in the venue via the Channels Mobile App for iOS devices
• Yamaha device ID allows simplified channel patching on CL consoles
• Smart Power Management on Transmitters: Advanced SB900A lithium-ion rechargeable batteries with SBC chargers provide extended transmitter battery life over alkaline batteries, battery-life metering in hours and minutes (accurate to within 15 minutes), and detailed tracking of battery health status

Give yourself wireless freedom with the quality sound and performance you can trust from Shure.
