Pinnacle Microphones X-Treme Stereo Ribbon Microphone

Stereo ribbon recording typically requires careful microphone placement, but the Pinnacle Microphones X-Treme stereo ribbon microphone integrates a complete Blumlein configuration into a single housing for consistent, repeatable results. Built with two matched, hand-tuned ribbon elements positioned vertically and offset at 90 degrees, it captures true stereo imaging without the need for multiple microphones or complex alignment. Its symmetrical figure-8 polar patterns and extended frequency response support accurate spatial detail with minimal off-axis coloration, while 135dB SPL handling maintains clarity across both subtle dynamics and higher-output sources. This design makes the X-Treme mic well suited for drum overheads, acoustic instruments, room capture and ensemble recording applications where stereo accuracy and workflow efficiency are critical.

Integrated Blumlein Design for Accurate Stereo Imaging

The X-Treme features two ribbon elements arranged in a fixed Blumlein configuration, allowing it to capture stereo sound with precise spatial detail and strong channel separation. The 90-degree offset between the ribbons preserves phase coherence while maintaining a stable stereo image across the soundfield. By housing both elements in a single chassis, the design eliminates the need for multi-microphone alignment, simplifying setup while ensuring consistent results across sessions.

Symmetrical Ribbon Design for Balanced Response

Each ribbon element is constructed from corrugated aluminum and positioned centrally within the magnetic field, supporting a true symmetrical figure-8 polar pattern. This design captures sound evenly from both the front and rear while reducing off-axis coloration and maintaining tonal consistency across the stereo field. With extended sensitivity, fast transient response and 135dB SPL handling, the microphone adapts to a wide range of sources, from close overhead placement to room and ensemble recording. For engineers seeking a compact stereo ribbon solution with accurate imaging and reliable performance, the Pinnacle Microphones X-Treme stereo ribbon mic provides a controlled and efficient approach to stereo capture.
