RCF EVOX JMIX-9 Active Three-Way Column Array System - White

When professional sound needs to travel light without sacrificing impact, the RCF EVOX JMIX-9 system delivers a compelling blend of power, clarity and control in a refined column array format. Built around a true three-way design, it pairs a wide-dispersion high-frequency section, articulate midrange array and a deep-reaching 12" subwoofer with an integrated digital mixer—making it a complete, self-contained PA for performers and events on the move. With 2100W of Class-D amplification, up to 130dB of maximum SPL and a low-profile enclosure that blends into virtually any environment, the JMIX-9 is engineered for DJs, bands, presenters and venues that demand professional results from a compact system.

True Three-Way Array With Coherent, Point-Source Clarity

At the core of the EVOX JMIX-9 is a true three-way acoustic design that delivers a natural, balanced sound field across the audience area. A 1.75" neodymium compression driver loaded onto RCF’s 120° × 40° True Resistive Waveguide provides wide, consistent high-frequency coverage, while six 3" full-range neodymium drivers handle the critical midrange with precision and punch. This alignment creates a unified acoustic center that radiates like a single point source, resulting in exceptional intelligibility, smooth phase response and even coverage from front row to back.

Deep, Controlled Low End With Touring-Grade Power

Low-frequency duties are handled by a high-power 12" RCF woofer housed in a bass-reflex enclosure, delivering tight, controlled lows that support everything from spoken word to bass-heavy music. Driven by a dual-channel Class-D amplifier rated at 2100W peak, the system maintains headroom and clarity even at higher output levels. Integrated DSP with FiRPHASE processing ensures phase-accurate response and musical transparency, helping vocals stay clear and instruments remain defined at any volume.

Integrated 8-Channel Digital Mixer With Onboard DSP

The EVOX JMIX-9 stands apart with its built-in 8-channel true-stereo digital mixer, eliminating the need for external mixing gear in many setups. Four studio-grade mic/line inputs with THAT preamps offer individual 48V phantom power, while onboard processing includes high-pass filters, one-knob compression and 3-band EQ on input channels. Reverb effects, AUX sends, and an 8-band EQ on the outputs provide comprehensive control, making it easy to tailor the system for different performers, rooms and applications.

Wireless Control and Bluetooth Streaming for Modern Workflows

Built-in Bluetooth streaming allows quick playback from mobile devices, while Bluetooth Low Energy connectivity enables full system control via the intuitive JMixRemote app. From a smartphone or tablet, users can adjust levels, EQ, dynamics and effects without touching the hardware—ideal for performers mixing themselves from the stage or engineers tuning the system from the room. A 2.4" color touch display and ergonomic encoders on the unit itself provide fast, hands-on access when needed.

A Complete, Professional PA Solution That’s Easy to Deploy

Finished in a sleek composite cabinet available in black or white, the EVOX JMIX-9 is designed to disappear visually while delivering unmistakable sonic presence. Dual-height configuration, a quick-fit pole mount and an included padded carrying bag make transport and setup straightforward, even for solo operators. Whether you’re running a live band, DJ set, corporate presentation or mobile event, the RCF EVOX JMIX-9 offers a reliable, great-sounding all-in-one PA solution that’s ready to perform wherever the gig takes you.
